MCMASTER-CARR
品牌名称:

MCMASTER-CARR

商品型号:91259A541
产地:USA
单位:pcs
Shoulder FitStandard
Shoulder Diameter1/4"
Shoulder Diameter Tolerance-0.004" to -0.002"
Shoulder Length7/8"
Shoulder Length Tolerance-0.005" to 0.005"
Thread Size10-24
Screw Size Decimal Equivalent0.190"
Thread TypeUNC
Thread SpacingCoarse
Thread FitClass 3A
Thread DirectionRight Hand
Thread Length3/8"
Head Diameter3/8"
Head Height3/16"
MaterialAlloy Steel
FinishBlack Oxide
HardnessRockwell C32
Tensile Strength140,000 psi
Minimum Shear Strength84,000 psi
Head TypeSocket
Socket Head ProfileStandard
Head TextureKnurled
Drive StyleHex
Drive Size1/8"
Specifications MetASME B18.3, ASTM A574
System of MeasurementInch
RoHSRoHS 3 (2015/863/EU) Compliant
REACHREACH (EC 1907/2006) (07/08/2021, 219 SVHC) Compliant
